P30
P30
Information
Add to Inquiry- OrientationRight Angle / Straight
- Circuits32P~40P
- Termination TypeDIP/ Wire Bonding
- Pitch3mm
| Features | |
|---|---|
| Pin Dimension | 0.64 mm x 0.64mm |
| Pitch | 3mm |
| Termination Type | DIP / Wire Bonding |
| Contact Current Rating | 2A |
| Dielectric withstanding Voltage | 1600V |
| Operating Temperature Range | -40°C~125°C |
| Wire Size | 24AWG |
| Housing Material | UL94V-0 |
| Vibration Class | V2 (Meets USCAR2-8 5.1.4.3) |
