Dynamic2000
Dynamic 2000
Information
Add to Inquiry- OrientationRight Angle
- Circuits8P~28P
- Termination TypeDIP / Wire Bonding
- Pitch2.5mm
| Features | |
|---|---|
| Pin Dimension | 0.5mm x 0.9mm |
| Pitch | 2.5mm |
| Termination Type | DIP/ Wire Bonding |
| Contact Current Rating | 5A |
| Dielectric withstanding Voltage | 1500V |
| Operating Temperature Range | -40°C~125°C |
| Wire Size | 20AWG ~ 22AWG |
| Housing Material | UL94V-0 |
| Vibration Class | V2 (Meets USCAR2-6 5.1.4.3) |
