IDC CONNECTOR
IDC CONNECTOR
Information
Add to Inquiry- OrientationStraight
- Circuits40P
- Termination TypeSMT / IDC Terminal+FPC
- Pitch2mm
| Features | |
|---|---|
| Pin Dimension | 0.4 mm x 0.5mm |
| Pitch | 2mm |
| Termination Type | SMT / IDC Terminal+ FPC |
| Contact Current Rating | 1A |
| Dielectric withstanding Voltage | 1600V |
| Operating Temperature Range | -40°C~125°C |
| Wire Size | 24 ~ 26AWG |
| Housing Material | UL94V-0 |
| Vibration Class | V2 (Meets USCAR2-8 5.1.4.3) |
